This solution offers a compact RFID TAG READER (which can be installed on a 2mm thickness support) and a control unit to be wired to a PLC. The system translates the TAG’s code in binary on 8 bits which allows to reach 255 different tags. This product is perfect for tool management. We provide batch of 100 screw types M6x 20mm in option. To use with a computeur, an interface with 8 inputs/RS232 will be required.
Max activation distance : up to 45mm
Contact : 8 x 200m APNP for 8-bit format
Detection encoding : 16 million
Indicator : 8 LEDs indicating the pathways activated
Reset : no
Mounting : symmetrical DIN 35mm rail after DIN 50022
Mounting : IP 54 electrical enclosure
Material : PA6
Electrical connection : Maximum 14 AWG (2.08mm²)
Temperature : -15°C…+60°C
Marking : label + serial number for traceability
Option : badge nail, screw, plate screw, key chain, card ... etc.
Application examples :
- Secured control of robotic tools or machines to avoid errors and incompatibilities.
- Keyed to blend Bigbag, tank, container contents
- Automatic sorting of products in harsh environments, without color or brightness or shape constraint
- Monitoring of batches (sleds, pallets, trays ... etc.)
- Production monitoring
- Selection of recipes for ready meals
- Operating mode and selective acknowledgment
- Tracking the authorization of operators in maintenance, production and regulation
- Access control store
- Replacement of a switch/selector in humid, dirty, aseptic environments
